Freitragendes Glasvordach, 77441270xxx-xx
Cantilevered glass canopy Nane
Length: 1500 mm | Surface: raw
Protect your entrance area in a stylish and modern way with the self-supporting glass canopy NANE. This elegant and high-quality canopy not only offers optimum weather protection, but also adds an architectural highlight to your home. Properties: Modern design: The frameless yet elegant design blends seamlessly into any façade design and adds a touch of exclusivity to your home entrance. High-quality materials: Made from rust-free aluminum, the NANE canopy not only offers aesthetic benefits, but also maximum stability and durability. Freestanding construction: Thanks to the self-supporting construction without disruptive supports, the entrance area remains spacious and open. Easy installation: The NANE canopy is supplied with detailed installation instructions. The pre-drilled holes and the supplied mounting material make installation quick and easy. Versatile use: Whether for private entrances or commercial areas - the NANE glass canopy is versatile and enhances any entrance area. Technical data: Dimensions: W 1500 mm x H 80 mm x D 100 mm, W 3000 mm x H 80 mm x D 100 mm Material: aluminum Use with: Laminated safety glass (VSG) made of TVG glass 17.52 mm Load capacity: Wind and snow load up to 3.8 kN/m2 (this corresponds to approx. 3.8 m new snow height with maximum projection and Sentry Glas®) max. projection: 1200 mm Colour silver matt anodized, raw Advantages: Optimal protection against rain and snow RAL color as desired (optional) High-quality and robust construction LED lighting optionally available Timeless and appealing design Quick and easy installation Easy to clean and weather-resistant Scope of delivery: 1 piece. Wall clamping profile with seals 2 pcs. End caps 1 pc. Glass fastening set 1 pc. wrench for locking cams
Details
Endkappen für freitragendes Glasvordach, 77441271000-xx
End caps for self-supporting glass canopy Nane
Surface: raw
The end caps for the wall clamping profile of the NANE glass canopy provide a clean, aesthetic finish to the side profile ends. They are supplied in a practical set of 2 and are installed by gluing, which ensures simple and secure fastening.
Details
Dichtungen für freitragendes Glasvordach, 7744127300000
Seals for self-supporting glass canopy Nane
The seals for the glass canopy NANE are essential components for the secure fastening and stabilization of the glass panes. They are specially designed for glass thicknesses from 16.76 to 17.52 mm and ensure reliable fixing and protection of the glass surfaces. With their high-quality workmanship, they make a significant contribution to the durability and safety of your NANE glass canopy.
Details
Drainage Adapter für Glasvordach, freitragend Sophia, 7744126003200
Drainage adapter for glass canopy, self-supporting Sophia Raine
The drainage adapter for connecting DN32 PVC pipes to the glass canopy, self-supporting Sophia.
Details
Glasvordach, freitragend, 29205xxxx46
Glass canopy, self-supporting Sophia
Glass thickness: 21.52 mm | Length: 5000 mm
Supported canopy SOPHIA is a frameless canopy system from G-Fittings that is supported solely by a narrow wall profile. The combination of wall clamping profile and special glass ensures an extraordinary load-bearing capacity of up to 150 kilos per square meter for the self-supporting glass canopy. The SOPHIA self-supporting glass canopy has a maximum projection of 130 cm. The maximum profile width is 500 cm. At this maximum width, the glass is distributed over two to three individual panes, making installation easier. The self-supporting SOPHIA glass canopy features a unique drainage system that channels rainwater out of the side of the profile. Optionally, you can turn your entrance area into a real eye-catcher by equipping the wall clamping profile with our LED flex strip set. This illuminates your canopy indirectly and can also serve as an orientation light without additional lights. Choose between neutral, white light or RGB with color change. If you are planning a very wide canopy, let our experts advise you without obligation. Canopy complete set Maximum projection of 130 cm Wall clamping profile made from high-quality aluminum New drainage system load capacity: 1.5 kN/m² Various lengths available (other dimensions on request.) Optional LED lighting Glass optionally available
Details
Glasvordach, freitragend, 2920x1xxx46
Glass canopy, self-supporting Farah
Glass thickness: 17.52 mm | Length: cut to size
The self-supporting, frameless FARA awning system is only supported by a narrow wall profile. The combination of wall clamp profile and special glass ensures an exceptionally high load capacity of up to 200 kilos per square metre. The maximum projection is a maximum of 1500 mm (with 25.52 mm SentryGlas®) Easy mounting and concealed mounting Up to 2 kN/m2 load capacity Glass width up to 5000 mm Easy mounting For glass thickness 17.52 mm, 21.52 mm and 25.52 mm SentryGlas® (optional available) max. 1500 mm projection No tie rods required Glass tilt can be adjusted later Several wall profiles can be connected
Details

Cantilevered glass canopy - elegance and functionality combined

Self-supporting canopies are an architectural masterpiece that are not only aesthetically pleasing but also extremely functional. These canopy constructions offer protection from the elements without the need for disruptive supporting pillars or columns. The unique design allows the canopy to float freely above the entrance area, creating an impressive visual effect while creating an open, welcoming atmosphere.

Cantilevered canopy:

A cantilevered canopy is characterized by its innovative design, where the roof is placed over the entrance area without any additional support structures. This allows maximum use of the available space and gives the building a modern and elegant appearance. Cantilevered glass canopies are particularly popular, as they not only provide effective weather protection, but also create a transparent and airy atmosphere. These glass canopies blend seamlessly into the architecture and allow plenty of light into the entrance area while protecting against rain, snow and sunlight.

Function of the cantilevered canopy:

The main function of a cantilevered canopy is to provide protection from the elements without reducing or obscuring the entrance area. The use of high-quality materials such as glass and aluminum ensures a durable and robust construction that not only enhances the appearance of the entrance area, but also protects it from external influences. The combination of wall clamping profile and special glass, for example, ensures exceptional load-bearing capacity.

Cantilever canopies are the ideal choice for modern buildings and architecture that strive for a harmonious combination of functionality and aesthetics. With their clean lines, transparent materials and cantilevered design, they create an elegant accent and add a touch of exclusivity to any entrance area.
