Glass door lock for sliding door Amita
Product number:
7746701000012
Description
The AMITA glass door lock is the elegant solution for modern sliding glass doors. Made from high-quality V2A stainless steel, it combines reliable security with a timeless look. Available in stainless steel or black, it can be perfectly matched to different furnishing styles and can be selected as keyed alike or keyed differently
The lock is designed for 10 mm glass thickness and offers a choice of keyed alike or keyed alike locking cylinders. AMITA therefore meets both functional and aesthetic requirements and integrates harmoniously into any sliding door system.
Key Features
V2A stainless steel
Stainless steel & black design
Keyed alike or keyed differently selectable
For sliding glass doors, 10 mm glass
Properties
| Depth in mm: | 44 mm |
|---|---|
| Door handle included: | no |
| Finish: | Stainless steel design |
| Glass cut outs: | yes |
| Glasstärke: | 10 mm |
| Height in mm: | 170 mm |
| Hook trap: | yes |
| Lockable: | yes |
| Material: | Stainless steel 304 (V2A) |
| Opening direction: | DIN left / DIN right |
| Profile cylinder included: | no |
| Strike plate included: | yes |
| Whisper Trap: | no |
| Width in mm: | 100 mm |
Downloads
| 77-46-7010-000-12_datasheet_G-FITTINGS.pdf | Datasheet | 255.95 KB |
|---|
