Hydraulic Swing door Marlouke
The MARLOUKE hydraulic swing door combines modern design with robust functionality and is ideal for demanding applications in doctors' surgeries, hotels, schools, offices, private homes and public buildings. Suitable for 8-12 mm thick glass and with a maximum door width of 900 mm and a maximum height of 3,000 mm, the swing door reliably holds door leaves weighing up to 100 kg. The door offers an attractive stainless steel or black design and impresses with its precise zero position adjustment and 90° hold-open in the open position. With an opening angle of up to 140° and a 2-way adjustable closing speed (140°-10° and 10°-0°), it offers flexibility and convenience. MARLOUKE contains a specially designed floor bearing and enables the door leaf to be opened and closed on both sides - the perfect solution for stylish and durable room partitioning.
Features at a glance
- Suitable for 8-12 mm glass
- Suitable for max. door width of 900 mm and max. door height of 3,000 mm
- Surfaces: Stainless steel or black design
- suitable for max. door weight of 100 kg
- with improved zero position adjustment
- with 90° hold-open function when the swing door is open
- Suitable for doctors' surgeries, hotels, schools, offices, private homes and public buildings
- Opening angle max. 140°
- 2-way adjustable closing speed (140°-10° and 10°-0°)
- 8 mm floor clearance required
- Glass processing required
- incl. uniquely designed floor bearing for the floor
- For opening and closing the door leaf on both sides
| Finish: | Stainless steel design |
|---|
| 77-45-0107-000-xx_technic_G-FITTINGS.pdf | Datasheet | 832.43 KB | |||
|---|---|---|---|---|---|
| 77-45-0106-000-xx_technic_G-FITTINGS.pdf | Datasheet | 1.30 MB |
