This products contains the following individual items:
Name | Quantity | |
---|---|---|
Square tube Carlotta
77114890035-12
|
0,65 m | |
Tube connector 80° Reidun
7711450203512
|
1 pcs | |
End cap for square tube Myntje
77114732035-12
|
1 pcs | |
Hinge adapter Lucilla
7710290000020
|
1 pcs | |
Stop adapter Petrine
77102950000-20
|
1 pcs | |
Glass clamp Aarnoudje
77102300000-20
|
2 pcs | |
Rubber inlay
7719501600800
|
4 pcs |
standard for 8 mm glass
File | Category | Size | Filetype | Prio |
---|---|---|---|---|
77-20-1231-035.dxf | CAD file | 3.37 MB | dxf |
Calculate glass: | W - 58 mm |
---|---|
Different dimensions possible: | yes |
Dimensions: | 35 x 35 mm |
Execution: | Endpost left |
Finish: | Stainless steel design |
Product type: | VMP (Pre-mounted product) |
Quantity glass holder: | 2 |
Tube type: | Square tube |
