Rectangular glass door lock with handles, non-locking Ande
Lock case for glass doors - rectangular and stylish
Discover the high-quality rectangular glass door lock with lever handles ANDE. This elegant door lock offers security and a modern design that blends seamlessly into any interior design
Made from robust AISI 304 (V2A) stainless steel, the lock case impresses with its durability and corrosion resistance. The stylish studio design and the carefully crafted finish are perfect for both private and commercial spaces. The lock is suitable for glass doors with a thickness of 8 to 10 mm and is available in the stylish finishes stainless steel, black and silver matt anodized.
Flexible for DIN left or right opening doors, it is supplied with lever handles for convenient handling. A whisper latch ensures quiet and gentle closing, and the striking plate included in the scope of delivery ensures stable installation.
Ideal for applications where ease of use is required, the ANDE lock case adds the finishing touch to your glass door - the perfect combination of functionality and modern design.
| Depth in mm: | 45 mm |
|---|---|
| Diameter Ø Glass hole: | 45 mm |
| Door handle included: | yes |
| Finish: | Stainless steel design |
| Glass cut outs: | yes |
| Glasstärke: | 8 - 10 mm |
| Height in mm: | 65 mm |
| Hook trap: | no |
| Lockable: | no |
| Look: | Studio |
| Magnetic: | no |
| Material: | Stainless steel 304 (V2A) |
| Opening direction: | DIN left , DIN right |
| Profile cylinder included: | no |
| Strike plate included: | yes |
| Through-bore: | yes |
| Whisper Trap: | yes |
| Width in mm: | 159 mm |
| 77-45-2260-001_datasheet_G-FITTINGS.pdf | Datasheet | 296.76 KB | |||
|---|---|---|---|---|---|
| 77-45-2260-001-xx.dxf | CAD file | 2.69 MB | dxf |
- Modern design
- Flexible for DIN left & DIN right
- for 8 - 10 mm glass
- Modern design
- Flexible for DIN left & DIN right
- for 8 - 10 mm glass
